Call our support team today if you need assistance finding the right tool for the job.
Finished precision ground on both sides & edges
One edge bevelled to 35 degrees
Note that SE1000GR0 - SE20000GR1 (Carbon Steel - Precision Straight Edge) is supplied with certification to DIN 874/0 or 874/1. Lapped on all 4 square sides. Ungraduated / no markings - CERTIFIED
| SKU | Description |
|---|---|
| SE1.5M | Carbon Steel - Ungraduated / no size markings, 1.5 metre length, 40mm width and 8mm thickness DIN 866 |
| SE2M | Carbon Steel - Ungraduated / no size markings, 2 metre length, 40mm width and 8mm thickness DIN 866 |
| SE3M | Carbon Steel - Ungraduated / no size markings, 3 metre length, 50mm width and 8mm thickness DIN 866 |
| SE500GRAD | Carbon Steel - Graduated markings every 1mm, 500mm length, 40mm width and 8mm thickness DIN 866 |
| SE1MGRAD | Carbon Steel - Graduated markings every 1mm, 1 metre length, 40mm width and 8mm thickness DIN 866 |
| SE1.5MGRAD | Carbon Steel - Graduated markings every 1mm, 1.5 metre length, 40mm width and 8mm thickness DIN 866 |
| SE2MGRAD | Carbon Steel - Graduated markings every 1mm, 2 metre length, 40mm width and 8mm thickness DIN 866 |
| SE3MGRAD | Carbon Steel - Graduated markings every 1mm, 3 metre length, 50mm width and 8mm thickness DIN 866 |
| SE1MSS | Stainless Steel - Ungraduated / no size markings, 1 metre length, 40mm width and 8mm thickness |
| SE2MSS | Stainless Steel - Ungraduated / no size markings, 2 metre length, 50mm width and 8mm thickness |
| SE1MGRADSS | Stainless Steel - Graduated markings every 1mm, 1 metre length, 40mm width and 8mm thickness |
| SE2MGRADSS | Stainless Steel - Graduated markings every 1mm, 2 metre length, 50mm width and 8mm thickness |
| SE1000GR0 | Carbon Steel - Precision Straight Edge (supplied with certification), 1 metre length, 60mm width, 12mm thickness and 874/0 standard |
| SE1000GR1 | Carbon Steel - Precision Straight Edge (supplied with certification), 1 metre length, 50mm width, 10mm thickness and 874/1 standard |
| SE1500GR1 | Carbon Steel - Precision Straight Edge (supplied with certification), 1.5 metre length, 60mm width, 12mm thickness and 874/1 standard |
| SE2000GR0 | Carbon Steel - Precision Straight Edge (supplied with certification), 2 metre length, 80mm width, 15mm thickness and 874/0 standard |
| SE2000GR1 | Carbon Steel - Precision Straight Edge (supplied with certification), 2 metre length, 70mm width, 15mm thickness and 874/1 standard |
| PSE125 | STRAIGHT EDGE PRISMATIC 125 mm - Double sided Bevelled Edge |
| PSE320 | STRAIGHT EDGE PRISMATIC 320 mm - Double sided Bevelled Edge |
View our range in our Latest Catalogue.
